Dividing Head Ratio: :1
Divisions:
Dividing plates (comma-separated list):
(these are typical plates, modify to match what you have)


This tool will allow you to input the list of your plates' holes and the divisions you want to achieve, then when you click on 'CALCULATE' you'll receive a table that shows which plate holes are compatible with the number of divisions you need, including the angles and sector settings to achieve those divisions.

If you don't find any matching plate holes for your desired number of divisions then check out the other calculator which will calculate what plate hole counts (and sector info) will yield the desired number of divisions.

If you want to generate a table, like in the original manual, for your dividing head then you can do that using this tool which will allow you to define a range of divisions and will generate a (possibly huge) table of possible plate hole (and sector info) for each division.
